Model
|
SUN-6K-SG01HP3 -EU-AM2
|
SUN-8K-SG01HP3- EU-AM2
|
SUN-10K-SG01HP3 -EU-AM2
|
SUN-12K-SG01HP3 -EU-AM2
|
SUN-15K-SG01HP3 -EU-AM2
|
SUN-20K-SG01HP3 -EU-AM2
|
|
Battery Input Data
|
||||||
|
Battery Type
|
Li-lon
|
|||||
|
Battery Voltage Range (V)
|
150~800
|
|||||
|
Max. Charging Current (A)
|
37
|
|||||
|
Max. Discharging Current (A)
|
37
|
|||||
|
PV String Input Data
|
||||||
|
Max. DC Input Power (W)
|
7800
|
10400
|
13000
|
15600
|
19500
|
26000
|
|
Max. DC Input Voltage (V)
|
1000
|
|||||
|
Start-up Voltage (V)
|
150
|
|||||
|
MPPT Range (V)
|
200-850
|
|||||
|
Rated DC Input Voltage (V)
|
600
|
|||||
|
PV Input Current (A)
|
20+20
|
26+20
|
26+26
|
|||
|
Max. PV I (A)
|
23+23
|
32+23
|
32+32
|
|||
|
No.of MPP Trackers
|
2
|
|||||
|
No.of Strings per MPP Tracker
|
1
|
2+1
|
2
|
|||
|
AC Output Data
|
||||||
|
Max. AC Output Power (W)
|
6600
|
8800
|
11000
|
13200
|
16500
|
22000
|
|
AC Output Rated Current (A)
|
9.1
|
12.2
|
15.2
|
18.2
|
22.8
|
30.3
|
|
Max. AC Current (A)
|
13
|
18
|
22
|
25
|
30
|
35
|
|
Max. Continuous AC Passthrough (A)
|
80
|
|||||
|
Peak Power (off grid)
|
1.5 time of rated power, 10 S
|
|||||
|
Output Frequency and Voltage
|
50/60Hz; 3L/N/PE 220/380, 230/400Vac
|
|||||
|
Grid Type
|
Three Phase
|
|||||
|
General Data
|
||||||
|
Communication with BMS
|
RS485; CAN
|
|||||
|
Weight (kg)
|
26
|
|||||
|
Size (mm)
|
434W×645H×245D
|
|||||
|
Protection Degree
|
IP65
|
|||||
|
Installation Style
|
Wall-mounted
|
|||||
|
Warranty
|
5 years
|
|||||
